MINI ITX Power Supply 12V Input 300W DC/ATX Power Supply

dc/dc atx Power Supply

DC ATX Switch PSU

MINI ITX Power Supply 12V Input 300W DC/ATX Power Supply,High efficiency,MINI ITX Power Supply 12V Input 300W DC/ATX
Power Supply,12V Input 300W DC/ATX Power Supply for Embedded PC Mini PC Car PC Boat PC Industrial,etc.



开关电源MINI ITX Power Supply 12V Input 300W DC/ATX Power Supply Size:

dc/atx power

开关电源MINI ITX Power Supply 12V Input 300W DC/ATX Power Supply Output interface :

20+4PIN 4pin SATA p4 m4pin
20+4 Pin Connector
4 Pin Molex Connector
SATA Connector
4 Pin 12V Connector
4 Pin Floppy Connector

开关电源Output parameter :

Model:LD300W
DC INPUT DC 12V
DC OUTPUT +12V +5V +3.3V -12V +5VSB

300W

MAX
COMINEO
WATTS
18A 8A 10A 0.15A 2.0A
POWER : 300W

开关电源Electrical Specification :

Model:LD300W
Rated power:300W
Input voltage range:12V DC (11.2VDC—14.8VDC)
Input surging current:12.0Vmax@12VDC
Work efficiency:≥90%
Working temperature/humidity:5℃ to 50℃ /45%-75%℃
Storage temperature/humidity:-40℃ to +70℃/10%-90%
Fanless DC-DC solution for 100% mute operating.
Compact design, special for mini-itx and 1U case.

开关电源aracteristics and advantages :

Strictly design and manufacture according to MINI-ITX power supply design specification.
Double sided PCB and SMT process are adopted.
High efficiency, small volume, good heat dissipation.
Multiple protection: over current, over voltage, short circuit multiple protection function.

Protection
(for+3.3V,+12V,+5.00V&+5.00VSB power output)
OCP:output shut down when output current reaches the peak point.
Short-circuit protection:output shut down when short-circuit.

开关电源MINI ITX Power Supply 12V Input 300W DC/ATX Power Supply Application :

MINI computer,one computer,POS machine,digital set top box,ITX case,network server,advertisement machine,bank terminal.etc.
